（广东隆宏发电机）LHGF系列柴油发电机,LONGHONG “隆宏企业牌”“鑫万迪牌”“互泰发电机”是我厂消化、吸收国外名牌先进技术而自行设计开发的新型产品。由我厂研制的具有当代国际水平的同步发电机与国内外知品牌柴油机同轴联接而成，并已批量投放市场。
*噪音降至68dB(a)～75dB(a)之间(距声源7m处测); *特设快速开启盖板，维护保养方便。
*开放式柴油发电机组直喷式燃烧室燃烧效率高，噪声低。
(Guangdong Longhong Generator) LHGF series diesel generators, Longhong "Longhong Enterprise Brand", "Xinwandi Brand" and "Hutai Generator" are new products designed and developed by our factory by digesting and absorbing advanced technology from foreign famous brands. The synchronous generator developed by our factory with contemporary international standards is coaxially connected with well-known domestic and foreign diesel engines, and has been put into the market in bulk.
GF series diesel generator structure:
*The whole machine is small in size, light in weight, compact in structure, and has a novel and beautiful appearance;
*The overall appearance of the machine is beautiful, easy to disassemble and assemble, and the unit operation is convenient;
*The use of specialized noise reduction and silencing materials greatly suppresses mechanical noise;
*Efficient shock absorption measures ensure the smooth operation of diesel generator sets;
*Automatic voltage regulator, with excellent performance and reliable operation;
*Large capacity engine base fuel tank, capable of continuous load operation for 10 hours;
*The noise level has decreased to between 68dB (a) and 75dB (a) (measured at a distance of 7m from the sound source);
*Specially designed quick opening cover plate for easy maintenance and upkeep.
*The direct injection combustion chamber of an open diesel generator set has high combustion efficiency and low noise.
This small generator adopts an integrated design and a completely independent configuration, which can meet the electricity requirements in any situation. Widely used in real estate, hotels, factories, postal and telecommunications, hotel buildings, entertainment venues, hospitals, shopping malls, industrial and mining enterprises, living areas and other places as a common or backup power source.
| 功率系列 Power series | 15KW | ||
| 发电机组型号 Model | LHGF-15 | ||
| 频率 Frequency Hz | 50 | ||
| 持续功率 Cont.AC output KW | 11 | ||
| 最大功率 Max.AC output KW | 12 | ||
| 电压 Voltage(A.C) V | 220/380 | ||
| 直流输出 DC output V-A | 12-8.3 | ||
发电机 Alternator | 电机型式 Type | 自励、恒压、旋转磁场、两极电机 Self excitation、constant voltage、field rotating、2 pole generator | |
| 定子尺寸 Stator size mm | φ245 × 130 | ||
| 相数 Phase | 单相Single phase/三相Three phase | ||
| 功率因数 Power factor CoSφ | 0.8 | ||
| 绝缘等级 Insulation | H(定子/转子Stator/rotor) | ||
| 发动机 Engine | 动力类型 Type | 双缸、V型/直列、四冲程、风冷柴油机 V-twin/L-twin、4-cycle、air-cooled diesel engine | |
| 动力型号 Model | DL2V88F | ||
| 缸径×冲程 Bore×stroke mm | 80×75 | ||
| 排 量 Displacement L | 0.912 | ||
| 压缩比 Compression ratio | 20:1 | ||
| 额定转速 Engine speed rpm | 3000 | ||
| 额定功率 Rated output kW | 13 | ||
| 燃烧方式 Combustion system | 直喷式Direct injection | ||
| 启动方式 Starting system | 电起动Electric starter | ||
| 机油容量 Lube oil capacity L | 2.8 | ||
| 机油牌号 Lubrication oil | CD级或更高CD grade or higher(SAE10W/30、SAE15W/40) | ||
| 燃油类型 Fuel oil | 柴油Diesel fuel(BS 2869 A1 orA2) | ||
| 发电机组 Generator set | 油箱容积 Fuel tank capacity L | 25 | |
| 燃油消耗 Fuel consunmption L/h | ≤3.9 | ||
| 7米噪音 Noise level at 7 m dB(A) | 71~73 | ||
| 尺寸 Dimension 长×宽×高 (L×W×H) mm | 1090 × 640 × 850 | ||
| 重量 Weight kg | 290 | ||
产品订购：佛山发电机15KW静音风冷柴油发电机组 220V/380V双电压输出 商铺及住宅小区应急备用
